AAP-1

Core Technology

• Audiophile Ultra Sonic Performance (AUSP™)
• Fully Protected High Efficiency Power Supply with Auto Selectable Mains (HEPS™)

Features

• Number of Channels: 2
• Power Rating @ 1% THD+N @ 1kHz (AES17 filter):
• 400WPC @ 8 Ohm
• 800WPC @ 4 Ohm
• Gain: 29dB
• Damping Factor: SE, <1kHz > 1000
• Frequency Response: -3dB @ 8 Ohm, 5Hz – 70kHz
• THD and Noise: (AES17 filter) @ 1kHz, 1W, RL = 8 Ohm, 0.003%
• Inter-modulation Distortion (CCIF): SE, 18kHz and 19kHz, Po = 10W, RL = 8 Ohm, 0.0008%
• Transient Inter-modulation Distortion (TIM): SE, Po = 10W @ 8 Ohm, 0.002%
• Dynamic Range: SE, Un-weighted / A-weighted, 118dB / 120dB
• Output Idle Noise: SE, Un-weighted / A-weighted, 75uVrms / 55uVrms
• Input Impedance: Balanced (XLR) 100k Ohm; Unbalanced (RCA) 50k Ohm
• Remote Trigger Voltage: AC/DC, 4-15V
• AC Voltage Range:
• 120Vac, 85-138 Vac
• 230Vac, 170-265 Vac
• Power Consumption:
• 1/8 Pink Noise @ 4 Ohm (Both Channels Driven) 300W
• Max 1,700W
• Standby 3W @120Vac, 6W @230Vac
